7HCN

City Technology Electrochemical cell - Hydrogen cyanide

More details...

Availability : This product is no longer in stock

Reference : 7HCN

497,35 € tax incl.

Ask for more quantity order

Notify me when available

Data sheet
More info

Output 100 ± 20 nA/ppm
Response Time Minore di 200 secondi (T90)
Target Gas Hydrogen Cyanide HCN
Measuring Range 0-100 ppm
Life expectancy Maggiore di 24 mesi

MEASUREMENT
Operating Principle: 3-electrode electrochemical
Measurement Range: 0 - 100 ppm HCN
Filter: None
Sensitivity: 0.10 ± 0.02 ?A/ppm
Response Time (T90): <200 Seconds at 20°C
Resolution (Electronics dependant): 0.5 ppm
Baseline Offset (clean air): -1 to +3 ppm equivalent

ELECTRICAL
Recommended Load Resistor: 10 ?
Bias Voltage: Not Required

MECHANICAL
Weight: 17 g
Housing Material:

Cap: Polycarbonate
Body: ABS

Orientation: Any

ENVIRONMENTAL
Operating Temperature Range: -20°C to +50°C
Recommended Storage Temp: 0°C to 20°C
Operating Pressure Range: Atmospheric ± 10%
Operating Humidity Range: 15 - 90% RH non-condensing

LIFETIME
Expected Operating Life: Two years in air
Storage Life: 6 months in CTL container
