FCB-EH6300

• Excellent high-definition (HD) picture quality

• The “Exmor” CMOS sensor realizes high image quality and high sensitivity

• Powerful zoom capability

• Various output modes

  - HD

  Analog: Component (Y/Pb/Pr)

  Digital: Y/Cb/Cr 4:2:2 via LVDS (Y: 8-bit, C: 8-bit, V-sync, H-sync, Field and Clock)

  - SD

  VBS

• Simple connection - one cable, one connector

  - Covering video, VISCA communication and power supply with a single cable.

  - Supports both 30-pin micro coaxial (digital and analog output) and 24-pin FFC (analog output only) interfaces.

• StableZoom™

  StableZoom is a function for performing correction using the image-stabilization function in accordance with the zoom ratio, and smoothly zooming up to approximately ×33 using a combination of the optical zoom and digital zoom. In StableZoom mode, this function starts naturally without bringing an abrupt change to the horizontal angle of view.

• Video Mode Change on The Fly

  Without any power cycle, this function makes it possible to change video mode, for example, from 1080p/29.97 mode to 720p/59.94 mode.

• Security-oriented functions include:
  Wide-D technology (On/Off/ Auto/Ratio fix)
  Day/Night function (On/Off/ Auto/Threshold enabled)
  Digital noise reduction (Up to 5 levels)
  Spherical privacy zone masking (24 zones with various PTZ controls)
  Motion detection alarm (4 zones with several triggering and threshold modes)

• Various modes for White Balance

  (Auto, AT W, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp Fix/Auto, One-push, Manual)

• Picture effects

  E-Flip, Nega Art, Black & White, Mirror Image, Colour Enhancement)

• Picture freeze

• Temperature readout

• Slow AE response (Approx. 5 min.)

• Title display (20 characters per line, max. 11 lines)

• Camera mode display (English)

• Electronic shutter/slow shutter

• Spot AE

• High Resolution Mode

• IR Focus Correction Function

• 4 Presets for Gamma Control

• 4 Levels of Chrominance Suppression

ATTENTION: DISCONTINUED PRODUCT
